FUNCTIONS1.Aligning & Conveying: Eggs are transported by the central egg‑collection system to the aligning table. After neat arrangement, eggs are conveyed to the subsequent process.
2.Orientation Adjustment: The orientation‑adjusting mechanism automatically aligns all eggs with their blunt‑end upward, so as to maintain egg freshness during storage.
3. Weight Grading: The weighing system weighs each individual egg. The system automatically records weight and quantity, and distributes eggs to discharge channels of corresponding grades.
4.Transmission System: Weighed eggs are transferred to the main drive track by independent robotic arms. Once inside the system, each egg moves independently to avoid damage from mutual collision.
5. Egg‑dropping Mechanism: The robotic arm gripping the eggs opens upon reaching the designated discharge channel. Eggs fall into flexible receiving buckets and then settle into egg trays.
6. Egg Tray Feeding: Two feeding modes, automatic and manual, are available based on actual site conditions.
7. Finished‑product Discharge: Tray‑loaded eggs are discharged via conveyor belt for manual or automatic palletizing.
8. Control System: Equipment parameter configuration and full‑machine operation are realized via touch screen. It supports quantity statistics for each egg grade and real‑time monitoring of system operating status.
FEATURES
- The machine can interface with the central egg‑collection system or automatic egg‑tray loader.
- It completes weight‑based grading and automatic tray loading. Eggs are placed blunt‑end upward to improve storage performance.
- Touch‑screen operation with configurable multiple weight grade levels.
- Compatible with standard paper egg trays and plastic egg trays.
- Support matching with automatic denester or manual denester.
